Water proof solar controller

Water Proof Solar Charger Controller Regulator for Solar Lighting System



EPRC-MF Water Proof Solar Charger Controller

SOLAR CONTROLLER FOR SOLAR STREET LIGHT SYSTEM

The MF series controller provides automatic lighting control function,

and its 100% water-proof, ensure longer lifetime. Good for humidity area,

such as outside pathway lighting, parking area, bus station, boat, etc.

Features

Microcontroller digital accuracy

PWM Charge mode

State of charge (SOC)

Temperature compensation with external temperature sensor

Detects day and night using the PV array

Water proof, IP66

LOAD ON TIME SETTING, DELAY TIME SETTING and BATTERY TYPE SETTING

Electronic protection

Short circuit protection

Reverse polarity protection

Reverse current protection at night

Over charging or discharging protection

Display

Charging indicator

Error icon

Load on time

Delay time

Battery type

Technical specification

EPRC-MF series: 12 VOLT or 12/24 VOLT auto work,                               10 AMPS (for PV and load)

Equalization voltage:

 14.8 Volt

Boost voltage:

14.4 Volt

Float voltage:

13.6 Volt

Low voltage disconnect (LVD)

11.10 Volt

Low voltages reconnect (LVR)

12.6Volt

Temperature compensation:

 -30mv//12V

Self-consumption:

6mA maximum

Terminals:

for wire sizes to 6mm2

Temperature:

 -35 to +55 Degree

Notes: It is for 12V system. Please X2 for 24V system.

WARRANTY: One year warranty period.
