5KW Off Grid Solar Home System

5KW off grid  Household Solar PV System--------Model: LQ-HS-5KW -AC
System Configuration
Series No.	Items	Specification	Quantity	G.W.
1	Solar Panel 5000Wp	125 W poly solar panel	40 PCS	440KG
2	Power Box	Controller 24V/ 60A	3 PCS	50KG
		Pure sine wave inverter24V/2000W	5 PCS
		Controller cabinet	1 PCS
3	Lead Acid Battery	24V/3000Ah,  not included in quotation and package
4	Accessories	Mounting brackets, cables 60m	1 SET	350KG
Reference for Use(System Capacity: 9000VA)
Name of Load	Power(W)	Quantity	Working Time per Day (H)	Working Days
Color TV	65W	1	6	2 rainy days
Satellite TV Receivers	25W	1	6
LCD Computer	100W	1	4
Energy-saving lamp	11W	6	6
Printer	30W	1	1
Electrograph	150W	1	1
Water Pump	200W	1	2
Refrigeratory	100W	1	24
Washing machine	300W	1	2
Air-condition	1000W	1	4
This system can provide electricity for home 6 hours per day. Peak output power of solar panel is 5000Wp. Capacity of battery: 24V/3000Ah System DC voltage: 24V; Output AC: 110V/220V, 50/60HZ Maximum power of loads:6000Wp;  Above loads can be powered simultaneously.

FOB QINGDAO CHINA USD $ 11155 ~ $ 11200/set
