PVDF Aluminum Composite Panel

PVDF Aluminum Composite Panel
Aluminium Composite Panel is a new decorative material used increasingly by developers, designers, and architects world wide for various applications. The advantages of using this material over conventional material like Stone, Tiles and paint are far too many.
Features:
1. High Peeling Strength
2. Superior Weathering Resistance
3. Light Weight and Easy for Process
4. Excellent Fire- Resistance Property
5. Coating Evenness & Diversified Colors
6. Easy for Maintenance
7. Impact Resistance
Scopes of Application:
1. Constructional exterior curtain walls.
2. Decorative renovation for storey-added old buildings.
3. Indoors decoration for interior walls, ceilings, bathrooms, kitchens and balconies.
4. Advertisement board, display platforms and signboards.
5. Wallboard and ceilings for tunnels.
6. Raw materials in industrial purpose.
7. Materials used for vehicle and boat 0.21x0.21mm, 0.15x0.15mm.

Product Specification

Property

Measurement

Panel Thickness

2mm, 3mm, 4mm, 5mm, 6mm

Aluminium Thickness

0.12mm, 0.15mm,0.18mm,0.21mm,0.30mm,0.40mm,0.50mm

Standard Panel Size

1220*2440mm, 1250*3200mm,1500*3200mm, 1500*6000mm.

Customs Panel Size

Max Width: 1800mm, Max Length: 6000mm

Panel Weight

2.5kg/m2 (2mm/0.12mm)
4.1kg/m2 (3mm/0.30mm)
4.9kg/m2 (4mm/0.30mm)
6.7kg/m2 (5mm/0.50mm)
7.5kg/m2 (6mm/0.50mm)



Panel Tolerances

Width

+/ -2mm

Length

+/ -3mm

Thickness

+/ -0.2mm

Diagonals Windage

Less than 3mm

Edge Wave

L ess than 1mm/m

Warpage

L ess than 3mm/m



Property

3 mm

4 mm

Surface Density

3.8~4.1kg/m2

4.9~5.8kg/m2

Bending Strength

68.3 MPa

120 MPa

Bending elastic modulus

2.02 x 10 4 MPa

2.81 x 10 4 MPa

Penetration resistance

5.0Kn

9.8Kn

Shearing Strength

20.4 MPa

29.8 MPa

180o Peal strength

6.3 N/mm

13.7 N/mm

Thermal expansion coefficient

5.7x 10-6 oC-1

7.9 x 10-6 oC-1

Heat distortion temperature

99 oC

105 oC



Coating Properties

3 mm PE

4 mm PVDF

Coating thickness

average 20 µm, min 19µm

average 29µm, min 28µm

Gloss tolerance

2.0 (gloss=25.8)

1.8 (gloss=42.2)

Pencil Hardness

3 H

3 H

Coating flexibility

1T

0T

Impact resistance

50Kg*cm no depainting, no crack

Washing and brushing

>10000 times no change

Aberration 3.0

1.4

Chalking Grade

Grade 1

Other aging properties

Grade 0
