2-Meter Width Aluminum Composite Signage Panel

Raw Material:

1. Basic aluminum: high strength aluminum alloy

2. Plastic core: non-toxic low density polyethylene

3. Surface coating: PVDF, PE paint

2 meter width aluminum composite panel brings a new vision which meets long span and large format design requirements,

satisfies various design needs and makes the cost of processings much cheaper, reducing scrap wastage, saving keel and other auxiliary material

and installation costs, the 2 meter width aluminum composite panel can be widely applied to the construction sector and signage making industry

and digital printing technology.

Product description:

Thickness: 3 mm ~ 6mm, recommended 3mm, 4mm

Length: up to 5800 mm, recommended: 2440mm, 3050mm, 4050mm

Aluminum thickness: 0.2~0.5mm

Coating: PVDF, PE, Spectra

Technical Data:

Parameter	Exterior	Interior
Coating Thickness(test)	>=25 um	>=16um
Coating Adhesive(test)	>=1 step
Gloss Tolerance(test)	Limit of error <=10
Pencil Hardness(test)	>=HB
Boiling water resistance(test)	No change
Color Difference test	<=3.0	-----
Acid resistance test	No change
Alkaline resistance test	No change
Grinding resistance test	>=5 um	-----
Bending test	>=100 Mpa	>=60Mpa
180 degree Peel strength 180	>=7N/mm	>=4N/mm
